Seat Arona
Date of manufacture
2017 – 6/2021 (Small SUV)
Platform
Volkswagen Group MQB A0
Manufacturing locations
Martorell, Spain
Designer
Alejandro Mesonero-Romanos
Tags
Small SUV
Spanish cars
The Seat Arona is a small SUV that has been manufactured in Spain since 2017. It is built on the Volkswagen Group MQB A0 platform and offers petrol and diesel engines. The most powerful model is the 1.5 TSI 150 with 110 kW of power, the fastest of them reaching a top speed of 207 km/h and the best acceleration from 0-100 km/h in 8.2 seconds. The most economical version, the 1.0 TGI 90, has a combined consumption of 4 kg/100 km and CO2 emissions of 109 g/km. The luggage compartment size is 282 l and the car received a 5 out of 5 rating from EURONCAP for safety in 2017.
Car body style
Small SUV
Date of manufacture
2017 – 6/2021Internal designation
KJ7
Technical data
Small SUV
| 1.0 TSI 95 | 1.0 TSI 110 | 1.0 TSI 110 | 1.0 TSI 115 | 1.0 TSI 115 | 1.5 TSI 150 | |
|---|---|---|---|---|---|---|
| Date of sale | - | from 2020 to | from 2020 to | from to 2020 | from to 2020 | from 2018 to |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 3/12 | 4/16 |
| Engine displacement [cm³] | 999 | 999 | 999 | 999 | 999 | 1498 |
| Maximum output / speed [kW/min-1] | 70/5000-5500 | 81/5500 | 81/5500 | 85/5000-5500 | 85/5000-5500 | 110/5000-6000 |
| Maximum torque [Nm/min-1] | 175/2000-3500 | 200/2000-3500 | 200/2000-3500 | 200/2000-3500 | 200/2000-3500 | 250/1500-3500 |
| Bore and stroke [mm x mm] | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 85,9 |
| Compression ratio | 10,5:1 | 10.5:1 | 10.5:1 | 10,5:1 | 10,5:1 | 10,5:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 5 gear manual | 6 gear manual | 7 gear automatic | 6 gear manual | 7 gear automatic | 6 gear manual |
| Drive specifications | - | - |
| - |
| - |
| Top speed [km/h] | 173-182 | 190 | 190 | 182 | 182 | 207-210 |
| Acceleration 0–100 km/h [s] | 11,4-11,5 | 10,3 | 10,1 | 9,8 | 10,0 | 8,2 |
| Acceleration 0–80 km/h [s] | 7.4 | - | - | 6.6 | - | 5.9 |
| Acceleration 80–120 km/h [s] | 11.4 | - | - | 11.9 | - | 9.2 |
| City [l] | 5,7-5,9 | 5,9 | 5,7 | 6.0-5,8 | 5.7-5,6 | 6,1-5,8 |
| Out of town [l] | 4,3-4,5 | 4,4 | 4,5 | 4,6-4.5 | 4,6-4.5 | 4.6-4.2 |
| Combined [l] | 4,8-5,0 | 5,0 | 4,9 | 5.1-5,0 | 5,0 | 5-4.9 |
| CO2 emissions [g/km] | 110,0-1 155,2 | 114 | 112 | 114-113 | 112 | 115-112 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 5,9-5,4 | undefined-5,7-5,3 | 5,9-6,2 | 6.3-5.9 | 6.3-6.0 | 6,4-5,8 |
| CO2 emissions [g/km] | 134-123 | undefined-129-120 | 133-141 | 142-133 | 143-137 | 145-131 |
| Emission standard | EU6 - Euro 6d-TEMP - Euro 6d | Euro 6d | Euro 6d | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | Euro 6d-TEMP - Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1164-1180 | 1193 | 1210 | 1189 | 1212 | 1224-1239 |
| Overall weight [kg] | 1615-1700 | 1720 | 1740 | 1625-1710 | 1655-1740 | 1665-1760 |
| Maximum trailer weight unbraked/braked [kg] | 580/1000 | - | - | 590/1100 | 600/1100 | 610/1200 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 55 | 55 | 55 | 55 | 55 | 55 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 400 | 400 | 400 | 400 | 400 | 400 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1280 | -/1280 | -/1280 | -/1280 | -/1280 | -/1280 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 40 | 40 | 40 | 40 | 40 | 40 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H |
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H |
| Wheel size front | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 |
| Wheel size rear | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 |
| Brake dimensions front | 276 x 24 | 276 x 24 | 276 x 24 | 276 x 24 | 276 x 24 | 276 x 24 |
| Brake dimensions rear | 228 x 42 drum | 230 x 9 | 230 x 9 | 230 x 9 | 230 x 9 | 230 x 9 |
| Steering | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering C-EPS |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- | 10.6/- |
| Overall length [mm] | 4138 | 4138 | 4138 | 4138 | 4138 | 4138 |
| Overall width without/including mirrors [mm] | 1780/1942 | 1780/1942 | 1780/1942 | 1780/1942 | 1780/1942 | 1780/1942 |
| Overall height [mm] | 1543 | 1543 | 1543 | 1543 | 1543 | 1543 |
| Wheelbase [mm] | 2566 | 2566 | 2566 | 2566 | 2566 | 2566 |
| Front wheel track [mm] | 1503 | 1503 | 1503 | 1503 | 1503 | 1503 |
| Rear wheel track [mm] | 1486 | 1486 | 1486 | 1486 | 1486 | 1486 |
| Forward overhang [mm] | 803 | 803 | 803 | 803 | 803 | 803 |
| Rear overhang [mm] | 769 | 769 | 769 | 769 | 769 | 769 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1059 | 1059 | 1059 | 1059 | 1059 | 1059 |
| Headroom rear [mm] | 990 | 990 | 990 | 990 | 990 | 990 |
| Front elbow/shoulder width [mm] | 1425/- | 1425/- | 1425/- | 1425/- | 1425/- | 1425/- |
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- | 1403/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 1.0 TGI 90 | 1.6 TDI 95 | 1.6 TDI 95 | 1.6 TDI 115 | |||
|---|---|---|---|---|---|---|
| Date of sale | from 2019 to | from to 2020 | from to 2020 | from to 2019 | ||
| Engine type | Ignition supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | ||
| Engine displacement [cm³] | 999 | 1598 | 1598 | 1598 | ||
| Maximum output / speed [kW/min-1] | 66/4500-5500 | 70/2750-4600 | 70/2750-4600 | 85/3250-4000 | ||
| Maximum torque [Nm/min-1] | 160/1800-3800 | 250/1500-2600 | 250/1500-2600 | 250/1500-3200 | ||
| Bore and stroke [mm x mm] | 74,5 x 76,4 | 79,5 x 80,5 | 79,5 x 80,5 | 79,5 x 80,5 | ||
| Compression ratio | 10,5:1 | 16,2:1 | 16,2:1 | 16,2:1 | ||
| Oil volume [l] | 4.3 | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 6 gear manual | 5 gear manual | 7 gear automatic | 6 gear manual | ||
| Drive specifications | - | - |
| - | ||
| Top speed [km/h] | 174 | 172 | 174 | 185 | ||
| Acceleration 0–100 km/h [s] | 13.2 | 11,9 | 12,8 | 10,5 | ||
| Acceleration 0–80 km/h [s] | 8.6 | - | - | - | ||
| Acceleration 80–120 km/h [s] | 17.8 | - | - | - | ||
| City [l] | 4.4 [6.7 m³] | 4,9-4.8 | 4,7-4.6 | 4,9 | ||
| Out of town [l] | 3.1 [4.7 m³] | 4,0-3.7 | 4,2-3.9 | 4,0 | ||
| Combined [l] | 3.5 [5.4 m³] | 4,3-4.1 | 4,4-4.2 | 4,3 | ||
| CO2 emissions [g/km] | 98-96 | 113-108 | 115-109 | 114 | ||
| Low speed [l] | - | - | - | - | ||
| Medium speed [l] | - | - | - | - | ||
| High speed [l] | - | - | - | - | ||
| Extra high speed [l] | - | - | - | - | ||
| Combined speed [l] | 4.0-3.9 kg | 5.1-4.8 | 5.4-5.2 | - | ||
| CO2 emissions [g/km] | 109-106 | 133-124 | 141-135 | - | ||
| Emission standard | Euro 6d-TEMP - Euro 6d | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | EU6 - Euro 6d-TEMP | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1308 | 1297 | 1320 | 1303 | ||
| Overall weight [kg] | 1710 | 1715-1800 | 1745-1830 | 1725-1810 | ||
| Maximum trailer weight unbraked/braked [kg] | - | 640/1200 | 660/1100 | 650/1200 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | 55 | 55 | 55 | ||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | ||
| Boot volume [l] | 282 | 400 | 400 | 400 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1162 | -/1280 | -/1280 | -/1280 | ||
| Boot length [mm] | - | - | - | - | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | - | - | - | - | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 9 [13.8 kg] | 40 | 40 | 40 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | ||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | ||
| Tyre dimensions front | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Tyre dimensions rear | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Wheel size front | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | ||
| Wheel size rear | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | 6J x 16 ET45 | ||
| Brake dimensions front | 276 x 24 | 276 x 24 | 276 x 24 | 276 x 24 | ||
| Brake dimensions rear | 228 x 42 drum | 230 x 9 | 230 x 9 | 230 x 9 | ||
| Steering | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering C-EPS | Rack & pinion with electro-mechanical power steering C-EPS | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 10.6/- | 10.6/- | 10.6/- | 10.6/- | ||
| Overall length [mm] | 4138 | 4138 | 4138 | 4138 | ||
| Overall width without/including mirrors [mm] | 1780/1942 | 1780/1942 | 1780/1942 | 1780/1942 | ||
| Overall height [mm] | 1552 | 1543 | 1543 | 1543 | ||
| Wheelbase [mm] | 2566 | 2566 | 2566 | 2566 | ||
| Front wheel track [mm] | 1503 | 1503 | 1503 | 1503 | ||
| Rear wheel track [mm] | 1486 | 1486 | 1486 | 1486 | ||
| Forward overhang [mm] | 803 | 803 | 803 | 803 | ||
| Rear overhang [mm] | 769 | 769 | 769 | 769 | ||
| Clearance [mm] | - | - | - | - | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1059 | 1059 | 1059 | 1059 | ||
| Headroom rear [mm] | 990 | 990 | 990 | 990 | ||
| Front elbow/shoulder width [mm] | 1425/- | 1425/- | 1425/- | 1425/- | ||
| Rear elbow/shoulder width [mm] | 1403/- | 1403/- | 1403/- | 1403/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
