Seat Ateca
Date of manufacture
2020 – to this day (Medium SUV)
Platform
Volkswagen Group MQB
Manufacturing locations
Kvasiny, Czechia
Relizane, Algeria
Designer
Christian Felske
Alejandro Mesonero-Romanos
Tags
Compact SUV
Spanish cars
The Seat Ateca is a mid-size SUV produced since 2020. It is manufactured in the Czech Republic and Algeria on the Volkswagen Group MQB platform. The engine range includes petrol and diesel engines with the highest power output of 140 kW (2.0 TSI 190 4Drive). This engine has a top speed of 214 km/h and a 0-100 km/h acceleration time of 7 seconds. The most fuel-efficient version is the 2.0 TDI 150 with a combined fuel consumption of 5.4 l/100 km and CO2 emissions of 141 g/km. The boot capacity is 510 litres. The model underwent EURONCAP safety tests in 2016 and received a rating of 5 out of 5.
Car body style
Medium SUV
after upgrade (facelift)
Date of manufacture
2020 – to this dayInternal designation
KH7
Technical data
Medium SUV
| 1.0 TSI 110 | 1.5 TSI 150 | 1.5 TSI 150 | 2.0 TSI 190 4Drive | 2.0 TDI 115 | 2.0 TDI 150 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 4/16 | 4/16 | 4/16 | 4/16 | 4/16 |
| Engine displacement [cm³] | 999 | 1498 | 1498 | 1984 | 1968 | 1968 |
| Maximum output / speed [kW/min-1] | 81/5500 | 110/5000-6000 | 110/5000-6000 | 140/4200-6000 | 85/2750-4250 | 110/3500-4000 |
| Maximum torque [Nm/min-1] | 200/2000-3000 | 250/1500-3500 | 250/1500-3500 | 320/1500-4100 | 300/1600-2500 | 340/1750-3000 |
| Bore and stroke [mm x mm] | 74,5 x 76,4 | 74,5 x 85,9 | 74,5 x 85,9 | 82,5 x 92,8 | 81,0 x 95,5 | 81,0 x 95,5 |
| Compression ratio | 11.5:1 | 10,5:1 | 10,5:1 | 12,2:1 | 16,0:1 | 16.0:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | 4x4 | Front | Front |
| Gearbox | 6 gear manual | 6 gear manual | 7 gear automatic | 7 gear automatic | 6 gear manual | 6 gear manual |
| Drive specifications |
| - |
|
|
|
|
| Top speed [km/h] | 180 | 200 | 200 | 214 | 185 | 203 |
| Acceleration 0–100 km/h [s] | 11,4 | 8,5 | 8,6 | 7,0 | 10,9 | 9,3 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6,3 | 6,5 | 6,3 | 7,9 | 5,8 | 5,6 |
| Out of town [l] | 5,1 | 5,3 | 5,2 | 6,1 | 3,8 | 3,8 |
| Combined [l] | 5,6 | 5,7 | 5,6 | 6,8 | 4,6 | 4,5 |
| CO2 emissions [g/km] | 127 | 131 | 127 | 155 | 120 | 118 |
| Low speed [l] | - | 7.9 | 8.6 | 10.2 | - | 6.2 |
| Medium speed [l] | - | 6.2 | 6.5 | 8.1 | - | 4.7 |
| High speed [l] | - | 5.7 | 5.8 | 6.9 | - | 4.2 |
| Extra high speed [l] | - | 6.8 | 7.0 | 8.0 | - | 5.4 |
| Combined speed [l] | 6,8-6,1 | 7,2-6,2 | 7,1-6,5 | 8,4-8,0 | 5,4-4,9 | 5,4-4,8 |
| CO2 emissions [g/km] | 155-137 | 163-141 | 162-149 | 192-181 | 142-127 | 141-126 |
| Emission standard | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d | Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | - | - | - | - | - | - |
| Driving noise [dB] | - | - | - | - | - | - |
| Standby weight [kg] | 1350 | 1400 | 1408 | 1558 | 1468 | 1483 |
| Overall weight [kg] | 1890 | 1930 | 1940 | 2090 | 2000 | 1990 |
| Maximum trailer weight unbraked/braked [kg] | 670/1300 | 700/1800 | 700/1600 | 750/1900 | 730/1500 | 740/1800 |
| Maximum front/rear axle load [kg] | - | - | - | - | - | - |
| Maximum vertical load on the tow bar [kg] | 88 | 88 | 88 | 88 | 88 | 88 |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | 75/- |
| Boot volume [l] | 510 | 510 | 510 | 485 | 510 | 510 |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1604 | -/1604 | -/1604 | -/1579 | -/1604 | -/1604 |
| Boot length [mm] | - | - | - | - | - | - |
| Boot length with rear seats folded [mm] | - | - | - | - | - | - |
| Boot width between wheels/max [mm] | - | - | - | - | - | - |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | - |
| Loading edge height [mm] | - | - | - | - | - | - |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | - | - | - | - | - | - |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5 | 5 | 5 | 5 | 5 | 5 |
| Fuel tank volume [l] | 50 | 50 | 50 | 55 | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | - | - |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | multilink | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | 215/60 R16 95V | 215/55 R17 94V | 215/55 R17 94V | 225/50 R18 95W | 215/55 R17 94V | 215/55 R17 94V |
| Tyre dimensions rear | 215/60 R16 95V | 215/55 R17 94V | 215/55 R17 94V | 225/50 R18 95W | 215/55 R17 94V | 215/55 R17 94V |
| Wheel size front | 6J x 16 ET43 | 7J x 17 ET45 | 7J x 17 ET45 | 7J x 18 ET45 | 6J x 16 ET43 | 6J x 16 ET43 |
| Wheel size rear | 6J x 16 ET43 | 7J x 17 ET45 | 7J x 17 ET45 | 7J x 18 ET45 | 6J x 16 ET43 | 6J x 16 ET43 |
| Brake dimensions front | 312 x 25 | 312 x 25 | 312 x 25 | 312 x 25 | 312 x 25 | 312 x 25 |
| Brake dimensions rear | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 | 272 x 10 |
| Steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- |
| Overall length [mm] | 4381 | 4381 | 4381 | 4381 | 4381 | 4381 |
| Overall width without/including mirrors [mm] | 1841/2078 | 1841/2078 | 1841/2078 | 1841/2078 | 1841/2078 | 1841/2078 |
| Overall height [mm] | 1601 | 1601 | 1601 | 1611 | 1601 | 1601 |
| Wheelbase [mm] | 2638 | 2638 | 2638 | 2630 | 2630 | 2630 |
| Front wheel track [mm] | 1576 | 1576 | 1576 | 1572 | 1572 | 1572 |
| Rear wheel track [mm] | 1541 | 1541 | 1541 | 1544 | 1544 | 1544 |
| Forward overhang [mm] | 871 | 871 | 871 | 871 | 871 | 871 |
| Rear overhang [mm] | 872 | 872 | 872 | 872 | 872 | 872 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | 1063 | 1063 | 1063 | 1063 | 1063 | 1063 |
| Headroom rear [mm] | 1020 | 1020 | 1020 | 1020 | 1020 | 1020 |
| Front elbow/shoulder width [mm] | 1483/- | 1483/- | 1483/- | 1483/- | 1483/- | 1483/- |
| Rear elbow/shoulder width [mm] | 1454/- | 1454/- | 1454/- | 1454/- | 1454/- | 1454/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| 2.0 TDI 150 | 2.0 TDI 150 4Drive | |||||
|---|---|---|---|---|---|---|
| Date of sale | - | - | ||||
| Engine type | Diesel supercharged | Diesel supercharged | ||||
| Number of cylinders/valves | 4/16 | 4/16 | ||||
| Engine displacement [cm³] | 1968 | 1968 | ||||
| Maximum output / speed [kW/min-1] | 110/3500-4000 | 110/3500-4000 | ||||
| Maximum torque [Nm/min-1] | 340/1750-3000 | 340/1750-3000 | ||||
| Bore and stroke [mm x mm] | 81,0 x 95,5 | 81,0 x 95,5 | ||||
| Compression ratio | 16.0:1 | 16.0:1 | ||||
| Oil volume [l] | - | - | ||||
| Coolant volume [l] | - | - | ||||
| Technical specifications |
|
| ||||
| Drive axle | Front | 4x4 | ||||
| Gearbox | 7 gear automatic | 7 gear automatic | ||||
| Drive specifications |
|
| ||||
| Top speed [km/h] | 202 | 197 | ||||
| Acceleration 0–100 km/h [s] | 9,0 | 8,7 | ||||
| Acceleration 0–80 km/h [s] | - | - | ||||
| Acceleration 80–120 km/h [s] | - | - | ||||
| City [l] | 5,2 | 5,7 | ||||
| Out of town [l] | 4,1 | 4,5 | ||||
| Combined [l] | 4,5 | 5,0 | ||||
| CO2 emissions [g/km] | 118 | 131 | ||||
| Low speed [l] | 6.6 | 7.5 | ||||
| Medium speed [l] | 4.9 | 5.6 | ||||
| High speed [l] | 4.4 | 5.1 | ||||
| Extra high speed [l] | 5.4 | 6.2 | ||||
| Combined speed [l] | 5,5-4,9 | 6,4-5,8 | ||||
| CO2 emissions [g/km] | 144-130 | 167-151 | ||||
| Emission standard | Euro 6d | Euro 6d | ||||
| Standard for fuel consumption measurement | - | - | ||||
| Energy class | - | - | ||||
| Stationary vehicle noise [dB] | - | - | ||||
| Driving noise [dB] | - | - | ||||
| Standby weight [kg] | 1514 | 1602 | ||||
| Overall weight [kg] | 2030 | 2130 | ||||
| Maximum trailer weight unbraked/braked [kg] | 750/1800 | 750/2100 | ||||
| Maximum front/rear axle load [kg] | - | - | ||||
| Maximum vertical load on the tow bar [kg] | 88 | 88 | ||||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | ||||
| Boot volume [l] | 510 | 485 | ||||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1604 | -/1579 | ||||
| Boot length [mm] | - | - | ||||
| Boot length with rear seats folded [mm] | - | - | ||||
| Boot width between wheels/max [mm] | - | - | ||||
| Boot height to headliner/ceiling [mm] | - | - | ||||
| Loading edge height [mm] | - | - | ||||
| Height of the open boot door [mm] | - | - | ||||
| Boot opening height [mm] | - | - | ||||
| Boot opening width min/max [mm] | - | - | ||||
| Number of doors | 5 | 5 | ||||
| Number of seats | 5 | 5 | ||||
| Fuel tank volume [l] | 50 | 55 | ||||
| AdBlue tank volume [l] | - | - | ||||
| Air resistance [Cd] | - | - | ||||
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | ||||
| Rear suspension | twist beam axle with trailing arms | multilink | ||||
| Tyre dimensions front | 215/55 R17 94V | 225/50 R18 95W | ||||
| Tyre dimensions rear | 215/55 R17 94V | 225/50 R18 95W | ||||
| Wheel size front | 6J x 16 ET43 | 7J x 18 ET45 | ||||
| Wheel size rear | 6J x 16 ET43 | 7J x 18 ET45 | ||||
| Brake dimensions front | 312 x 25 | 312 x 25 | ||||
| Brake dimensions rear | 272 x 10 | 272 x 10 | ||||
| Steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | ||||
| Number of steering wheel turns | - | - | ||||
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | ||||
| Overall length [mm] | 4381 | 4381 | ||||
| Overall width without/including mirrors [mm] | 1841/2078 | 1841/2078 | ||||
| Overall height [mm] | 1601 | 1611 | ||||
| Wheelbase [mm] | 2630 | 2630 | ||||
| Front wheel track [mm] | 1572 | 1572 | ||||
| Rear wheel track [mm] | 1544 | 1544 | ||||
| Forward overhang [mm] | 871 | 871 | ||||
| Rear overhang [mm] | 872 | 872 | ||||
| Clearance [mm] | - | - | ||||
| Wading depth [mm] | - | - | ||||
| Approach angle front [°] | - | - | ||||
| Approach angle rear [°] | - | - | ||||
| Transition angle [°] | - | - | ||||
| Climbing rate [°] | - | - | ||||
| Maximum side tilt [°] | - | - | ||||
| Headroom front [mm] | 1063 | 1063 | ||||
| Headroom rear [mm] | 1020 | 1020 | ||||
| Front elbow/shoulder width [mm] | 1483/- | 1483/- | ||||
| Rear elbow/shoulder width [mm] | 1454/- | 1454/- | ||||
| Legroom front knees/total [mm] | - | - | ||||
| Legroom rear knees/total [mm] | - | - |
