Škoda Fabia
Date of manufacture
2019 – 2021 (Five-door hatchback)
2019 – 2021 (Estate)
Platform
Volkswagen Group A06 PQ26
Manufacturing locations
Mladá Boleslav, Czechia
Relizane, Algeria
Designer
Jozef Kabaň
Tags
B-segment
Czech cars
The Škoda Fabia model has a body style of five-door hatchback and estate. The car has been manufactured since 2019. The car is produced in countries such as the Czech Republic and Algeria. The car is built on the Volkswagen Group A06 PQ26 platform. The engine range only has petrol engines. The most powerful car is the 1.0 TSI 110 with a power output of 81 kW. The 1.0 TSI 110 is the fastest model in the range. The top speed is 196 km/h. The best 0-100 km/h acceleration of 9.6 seconds is achieved by the 1.0 TSI 110 model. The lowest combined fuel consumption of 4.5 l/100 km is achieved by the 1.0 TSI 95 model. CO2 emissions are 105 g/km. The estate body style offers a luggage compartment volume of 530 l. The five-door hatchback body style has a luggage compartment volume of 330 l. The model was tested for safety in 2014 and achieved an overall rating of 5 out of 5 according to EURONCAP.
Car body style
Five-door hatchback
Date of manufacture
2019 – 2021Internal designation
NJ3Engine size
Estate
Date of manufacture
2019 – 2021Internal designation
NJ5Engine size
Technical data
Five-door hatchback
| 1.0 MPI | 1.0 MPI | 1.0 TSI 95 | 1.0 TSI 110 | 1.0 TSI 110 | ||
|---|---|---|---|---|---|---|
| Date of sale | - | from to 2019 | - | - | from to 2019 | |
| Engine type | Petrol | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 3/12 | |
| Engine displacement [cm³] | 999 | 999 | 999 | 999 | 999 | |
| Maximum output / speed [kW/min-1] | 44/5000-6000 | 55/6200 | 70/5000-5500 | 81/5500 | 81/5500 | |
| Maximum torque [Nm/min-1] | 95/3000-4300 | 95/3000-4300 | 175/2000-3500 | 200/2000-3500 | 200/2000-3500 | |
| Bore and stroke [mm x mm] | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | |
| Compression ratio | 10,5:1 | 10,5:1 | 10.5:1 | 10.5:1 | 10.5:1 | |
| Oil volume [l] | - | - | - | - | - | |
| Coolant volume [l] | - | - | - | - | - | |
| Technical specifications |
|
|
|
|
| |
| Drive axle | Front | Front | Front | Front | Front | |
| Gearbox | 5 gear manual | 5 gear manual | 5 gear manual | 6 gear manual | 7 gear automatic | |
| Drive specifications | - | - | - | - |
| |
| Top speed [km/h] | 158 | 168 | 184-185 | 195-196 | 194 | |
| Acceleration 0–100 km/h [s] | 16,4 | 14.9 | 10,7-10,8 | 9,6-9,7 | 10.1 | |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | |
| City [l] | 5,9-5,7 | 6.0 | 5.7-5.5 | 5,9-5,6 | 5.5-5.3 | |
| Out of town [l] | 4,3 | 4.3 | 4,2-3,9 | 4,4-4,0 | 4.4-4.3 | |
| Combined [l] | 4,8 | 4.9 | 4,8-4,5 | 4,9-4,6 | 4.8-4.7 | |
| CO2 emissions [g/km] | 110-109 | 111 | 109-103 | 113-104 | 110-106 | |
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | |
| Standard for fuel consumption measurement | - | - | - | - | - | |
| Energy class | - | - | - | - | - | |
| Stationary vehicle noise [dB] | - | - | - | - | - | |
| Driving noise [dB] | - | - | - | - | - | |
| Standby weight [kg] | 1081-1186 | 1086 | 1116-1221 | 1127-1232 | 1165 | |
| Overall weight [kg] | 1536 | 1541 | 1571-1576 | 1582-1587 | 1620 | |
| Maximum trailer weight unbraked/braked [kg] | 540/800 | 540/800 | 550-560/1000 | 560/1100 | 560/1100 | |
| Maximum front/rear axle load [kg] | - | - | - | - | - | |
| Maximum vertical load on the tow bar [kg] | 50 | - | 50 | 50 | - | |
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | 75/- | |
| Boot volume [l] | 330 | 330 | 330 | 330 | 330 | |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1150 | -/1150 | -/1150 | -/1150 | -/1150 | |
| Boot length [mm] | 716 | 716 | 716 | 716 | 716 | |
| Boot length with rear seats folded [mm] | - | - | - | - | - | |
| Boot width between wheels/max [mm] | -/960 | -/960 | -/960 | -/960 | -/960 | |
| Boot height to headliner/ceiling [mm] | - | - | - | - | - | |
| Loading edge height [mm] | - | - | - | - | - | |
| Height of the open boot door [mm] | - | - | - | - | - | |
| Boot opening height [mm] | - | - | - | - | - | |
| Boot opening width min/max [mm] | - | - | - | - | - | |
| Number of doors | 5 | 5 | 5 | 5 | 5 | |
| Number of seats | 5 | 5 | 5 | 5 | 5 | |
| Fuel tank volume [l] | 45 | 45 | 45 | 45 | 45 | |
| AdBlue tank volume [l] | - | - | - | - | - | |
| Air resistance [Cd] | 0.327-0.335 | 0.327-0.335 | 0.327-0.335 | 0.327-0.335 | 0.327-0.335 | |
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | |
| Tyre dimensions front | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | |
| Tyre dimensions rear | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | |
| Wheel size front | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | |
| Wheel size rear | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | |
| Brake dimensions front | - | - | - | - | - | |
| Brake dimensions rear | - | - | - | - | - | |
| Steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | |
| Number of steering wheel turns | - | - | - | - | - | |
| Turning diameter track/circumference [m] | -/10.4 | -/10.4 | -/10.4 | -/10.4 | -/10.4 | |
| Overall length [mm] | 3997 | 3997 | 3997 | 3997 | 3997 | |
| Overall width without/including mirrors [mm] | 1732/1958 | 1732/1958 | 1732/1958 | 1732/1958 | 1732/1958 | |
| Overall height [mm] | 1467 | 1467 | 1467 | 1467 | 1467 | |
| Wheelbase [mm] | 2470 | 2470 | 2470 | 2470 | 2470 | |
| Front wheel track [mm] | 1463 | 1463 | 1457 | 1457 | 1457 | |
| Rear wheel track [mm] | 1457 | 1457 | 1451 | 1451 | 1451 | |
| Forward overhang [mm] | 852 | 852 | 852 | 852 | 852 | |
| Rear overhang [mm] | 676 | 676 | 676 | 676 | 676 | |
| Clearance [mm] | 133 | 133 | 133 | 133 | 133 | |
| Wading depth [mm] | - | - | - | - | - | |
| Approach angle front [°] | 14.4 | 14.4 | 14.4 | 14.4 | 14.4 | |
| Approach angle rear [°] | 17.4 | 17.4 | 17.4 | 17.4 | 17.4 | |
| Transition angle [°] | - | - | - | - | - | |
| Climbing rate [°] | - | - | - | - | - | |
| Maximum side tilt [°] | - | - | - | - | - | |
| Headroom front [mm] | 1021 | 1021 | 1021 | 1021 | 1021 | |
| Headroom rear [mm] | 963 | 963 | 963 | 963 | 963 | |
| Front elbow/shoulder width [mm] | 1401/- | 1401/- | 1401/- | 1401/- | 1401/- | |
| Rear elbow/shoulder width [mm] | 1386/- | 1386/- | 1386/- | 1386/- | 1386/- | |
| Legroom front knees/total [mm] | - | - | - | - | - | |
| Legroom rear knees/total [mm] | - | - | - | - | - | |
| Rating | - | - |   | - | - | |
| Clean Air Index | - | - | 6.0/10 | - | - | |
| Energy Efficiency Index | - | - | 6.5/10 | - | - | |
| GHG index | - | - | 5.0/10 | - | - |
Estate
| 1.0 MPI | 1.0 TSI 95 | 1.0 TSI 110 | 1.0 TSI 110 | |||
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | ||
| Engine type | Petrol | Ignition supercharged | Ignition supercharged | Ignition supercharged | ||
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | ||
| Engine displacement [cm³] | 999 | 999 | 999 | 999 | ||
| Maximum output / speed [kW/min-1] | 55/6200 | 70/5000-5500 | 81/5500 | 81/5500 | ||
| Maximum torque [Nm/min-1] | 95/3000-4300 | 175/2000-3500 | 200/2000-3500 | 200/2000-3500 | ||
| Bore and stroke [mm x mm] | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | 74,5 x 76,4 | ||
| Compression ratio | 10,5:1 | 10.5:1 | 10.5:1 | 10.5:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 5 gear manual | 5 gear manual | 6 gear manual | 7 gear automatic | ||
| Drive specifications | - | - | - |
| ||
| Top speed [km/h] | 169 | 185-187 | 196-198 | 195 | ||
| Acceleration 0–100 km/h [s] | 15.2 | 10,8-10.9 | 9,7 | 10.2 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | 6.0 | 5,7-5.4 | 5,7-5,6 | 5.7 | ||
| Out of town [l] | 4.2 | 3,8-4.1 | 4,0-3,9 | 4.3 | ||
| Combined [l] | 4.9 | 4,5-4.6 | 4,7-4,5 | 4.8 | ||
| CO2 emissions [g/km] | 111 | 105-102 | 106-104 | 110 | ||
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | Euro 6d-TEMP | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | - | - | - | - | ||
| Driving noise [dB] | - | - | - | - | ||
| Standby weight [kg] | 1106 | 1136-1241 | 1147-1252 | 1185 | ||
| Overall weight [kg] | 1561 | 1591 | 1602 | 1640 | ||
| Maximum trailer weight unbraked/braked [kg] | 550/800 | 570/1000 | 570/1100 | 570/1100 | ||
| Maximum front/rear axle load [kg] | - | - | - | - | ||
| Maximum vertical load on the tow bar [kg] | - | 50 | 50 | 50 | ||
| Maximum load on roof/carrier [kg] | 75/- | 75/- | 75/- | 75/- | ||
| Boot volume [l] | 530 | 530 | 530 | 530 | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | -/1395 | -/1395 | -/1395 | -/1395 | ||
| Boot length [mm] | 958 | 958 | 958 | 958 | ||
| Boot length with rear seats folded [mm] | - | - | - | - | ||
| Boot width between wheels/max [mm] | -/960 | -/960 | -/960 | -/960 | ||
| Boot height to headliner/ceiling [mm] | - | - | - | - | ||
| Loading edge height [mm] | - | - | - | - | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | - | - | - | - | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5 | 5 | 5 | 5 | ||
| Fuel tank volume [l] | 45 | 45 | 45 | 45 | ||
| AdBlue tank volume [l] | - | - | - | - | ||
| Air resistance [Cd] | 0.324-0.330 | 0,316 | 0,311 | 0,311 | ||
| Front suspension | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | MacPherson, lower triangular arms, torsion stabiliser | ||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | ||
| Tyre dimensions front | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | ||
| Tyre dimensions rear | 185/60 R15 | 185/60 R15 | 185/60 R15 | 185/60 R15 | ||
| Wheel size front | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | ||
| Wheel size rear | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | 6,0J x 15 | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | Rack & pinion with electro-mechanical power steering | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | -/10.4 | -/10.4 | -/10.4 | -/10.4 | ||
| Overall length [mm] | 4262 | 4262 | 4262 | 4262 | ||
| Overall width without/including mirrors [mm] | 1732/1958 | 1732/1958 | 1732/1958 | 1732/1958 | ||
| Overall height [mm] | 1488 | 1488 | 1488 | 1488 | ||
| Wheelbase [mm] | 2470 | 2470 | 2470 | 2470 | ||
| Front wheel track [mm] | 1463 | 1457 | 1457 | 1457 | ||
| Rear wheel track [mm] | 1457 | 1451 | 1451 | 1451 | ||
| Forward overhang [mm] | 852 | 852 | 852 | 852 | ||
| Rear overhang [mm] | 940 | 940 | 940 | 940 | ||
| Clearance [mm] | 135 | 135 | 135 | 135 | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | 14.4 | 14.4 | 14.4 | 14.4 | ||
| Approach angle rear [°] | 13.1 | 13.1 | 13.1 | 13.1 | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | 1021 | 1021 | 1021 | 1021 | ||
| Headroom rear [mm] | 967 | 967 | 967 | 967 | ||
| Front elbow/shoulder width [mm] | 1401/- | 1401/- | 1401/- | 1401/- | ||
| Rear elbow/shoulder width [mm] | 1386/- | 1386/- | 1386/- | 1386/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - |
