	1.6 VVT	2.0	2.0	2.4 VVT	2.4 VVT	3.2 V6
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Petrol	Petrol
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	6/24
Engine displacement [cm³]	1586	1995	1995	2393	2393	3195
Maximum output / speed [kW/min-1]	78/5900	103/6000	103/6000	124/6000	124/6000	171/6200
Maximum torque [Nm/min-1]	145/4100	183/4000	183/4000	227/3800	227/3800	291/3200
Bore and stroke [mm x mm]	78,0 x 83,0	84,0 x 90,0	84,0 x 90,0	92,0 x 90,0	92,0 x 90,0	89,0 x 85,6
Compression ratio	10,5:1	10,5:1	10,5:1	10,0:1	10,0:1	10,0:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake valves VVT	-	-	variable timing of intake valves VVT	variable timing of intake valves VVT	-

Drive axle	4x4	4x4	4x4	4x4	4x4	4x4
Gearbox	5 gear manual	5 gear manual	4 gear automatic	5 gear manual	4 gear automatic	5 gear automatic
Drive specifications	permanent all-wheel drive 4H	automatically controlled all-wheel drive 4‐mode	automatically controlled all-wheel drive 4‐mode automatic gearbox	automatically controlled all-wheel drive 4‐mode	automatically controlled all-wheel drive 4‐mode automatic gearbox	automatically controlled all-wheel drive 4‐mode automatic gearbox

Top speed [km/h]	160	175	170	185	175	200
Acceleration 0–100 km/h [s]	14.4	12.5	13.6	11.7	12.0	9.3
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	10.2-10.4	10.6-11.2	11.5	11.4-12.3	12.5-13.3	14.4-14.7
Out of town [l]	7.1-7.3	7.2-7.4	7.7	7.6	8.1-8.4	8.3-8.4
Combined [l]	8.2-8.4	8.4-8.8	9.1	9.0-9.3	9.7-10.2	10.6-10.7
CO2 emissions [g/km]	195-199	199	210	208	225	245

Emission standard	EU4-EU5	EU4	EU4	EU4-EU5	EU4-EU5	EU4
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1405-1481	1533-1643	1548-4658	1552-1655	1567-1670	1677-1753
Overall weight [kg]	1830	2070	2070	2100	2100	2170
Maximum trailer weight unbraked/braked [kg]	550/1600	750/1850	750/1700	750/1850	750/1700	750/2000
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	184	398	398	398	398	398
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/964	-/1386	-/1386	-/1386	-/1386	-/1386
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	3	5	5	5	5	5
Number of seats	4	5	5	5	5	5
Fuel tank volume [l]	55	66	66	66	66	66
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson	MacPherson
Rear suspension	multilink	multilink	multilink	multilink	multilink	multilink
Tyre dimensions front	225/70 R16	225/70 R16	225/70 R16	225/65 R17	225/65 R17	225/60 R18
Tyre dimensions rear	225/70 R16	225/70 R16	225/70 R16	225/65 R17	225/65 R17	225/60 R18
Wheel size front	-	-	-	-	-	-
Wheel size rear	-	-	-	-	-	-
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.2/-	11.0/-	11.0/-	11.0/-	11.0/-	11.0/-

Overall length [mm]	4060	4300	4300	4300	4300	4300
Overall width without/including mirrors [mm]	1810/-	1810/-	1810/-	1810/-	1810/-	1810/-
Overall height [mm]	1695	1695	1695	1695	1695	1695
Wheelbase [mm]	2440	2640	2640	2640	2640	2640
Front wheel track [mm]	1540	1540	1540	1540	1540	1540
Rear wheel track [mm]	1570	1570	1570	1570	1570	1570
Forward overhang [mm]	785	785	785	785	785	785
Rear overhang [mm]	875	875	875	875	875	875
Clearance [mm]	200	200	200	200	200	200
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	29	29	29	29	29	29
Approach angle rear [°]	36	27	27	27	27	27
Transition angle [°]	20	19	19	19	19	19
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	1.9 DDiS	1.9 DDiS
Date of sale	-	-
Engine type	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/8	4/8
Engine displacement [cm³]	1870	1870
Maximum output / speed [kW/min-1]	95/3750	95/3750
Maximum torque [Nm/min-1]	300/2000	300/2000
Bore and stroke [mm x mm]	80,0 x 93,0	80,0 x 93,0
Compression ratio	17,0:2	17,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	direct injection Common Rail turbo-supercharged	direct injection Common Rail turbo-supercharged particulate filter (EU5)

Drive axle	4x4	4x4
Gearbox	5 gear manual	5 gear manual
Drive specifications	automatically controlled all-wheel drive 4‐mode	automatically controlled all-wheel drive 4‐mode

Top speed [km/h]	170	170
Acceleration 0–100 km/h [s]	12.8	13.2
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	8.3-8.7	8.1-9.0
Out of town [l]	6.2	6.0-6.4
Combined [l]	7.0-7.2	6.8-7.4
CO2 emissions [g/km]	183-189	179-191

Emission standard	EU4	EU4-EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1527-1608	1630-1741
Overall weight [kg]	1940	2170
Maximum trailer weight unbraked/braked [kg]	550/1600	750/2000
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	184	398
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1386	-/1386
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	3	5
Number of seats	4	5
Fuel tank volume [l]	55	66
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	multilink	multilink
Tyre dimensions front	225/70 R16	225/70 R16
Tyre dimensions rear	225/70 R16	225/70 R16
Wheel size front	-	-
Wheel size rear	-	-
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	Rack & pinion with hydraulic power steering	Rack & pinion with hydraulic power steering
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.2/-	11.0/-

Overall length [mm]	4060	4300
Overall width without/including mirrors [mm]	1810/-	1810/-
Overall height [mm]	1695	1695
Wheelbase [mm]	2440	2640
Front wheel track [mm]	1540	1540
Rear wheel track [mm]	1570	1570
Forward overhang [mm]	785	785
Rear overhang [mm]	875	875
Clearance [mm]	200	190
Wading depth [mm]	-	-
Approach angle front [°]	29	29
Approach angle rear [°]	36	27
Transition angle [°]	20	19
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-
