Suzuki Kizashi

Date of manufacture

2009 – 12/2014 (Sedan)

Platform

Manufacturing locations

Makinohara, Japan

Designer

Car body style

Sedan

Date of manufacture

2009 – 12/2014

Internal designation

Engine size

2.4 VVT

Technical data

Sedan

	2.4 VVT	2.4 VVT
Date of sale	-	-
Engine type	Petrol	Petrol
Number of cylinders/valves	4/16	4/16
Engine displacement [cm³]	2393	2393
Maximum output / speed [kW/min-1]	131/6500	131/6500
Maximum torque [Nm/min-1]	230/4000	230/4000
Bore and stroke [mm x mm]	92,0 x 90,0	92,0 x 90,0
Compression ratio	10,0:1	10,0:1
Oil volume [l]	-	-
Coolant volume [l]	-	-
Technical specifications	variable timing of intake valves VVT	variable timing of intake valves VVT

Drive axle	Front	4x4
Gearbox	6 gear manual	1 gear automatic
Drive specifications	-	connectable all-wheel drive i‐AWD automatic gearbox with one variable ratio CVT s jedním variabilním převodem

Top speed [km/h]	215	205
Acceleration 0–100 km/h [s]	7.8	8.8
Acceleration 0–80 km/h [s]	-	-
Acceleration 80–120 km/h [s]	-	-

City [l]	10.6	11.3
Out of town [l]	6.3	6.6
Combined [l]	7.9	8.3
CO2 emissions [g/km]	183	191

Emission standard	EU5	EU5
Standard for fuel consumption measurement	-	-
Energy class	-	-
Stationary vehicle noise [dB]	-	-
Driving noise [dB]	-	-

Standby weight [kg]	1420	1530
Overall weight [kg]	2000	2030
Maximum trailer weight unbraked/braked [kg]	-	-
Maximum front/rear axle load [kg]	-	-
Maximum vertical load on the tow bar [kg]	-	-
Maximum load on roof/carrier [kg]	-	-

Boot volume [l]	461	461
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-
Boot length [mm]	-	-
Boot length with rear seats folded [mm]	-	-
Boot width between wheels/max [mm]	-	-
Boot height to headliner/ceiling [mm]	-	-
Loading edge height [mm]	-	-
Height of the open boot door [mm]	-	-
Boot opening height [mm]	-	-
Boot opening width min/max [mm]	-	-

Number of doors	4	4
Number of seats	5	5
Fuel tank volume [l]	63	63
AdBlue tank volume [l]	-	-
Air resistance [Cd]	-	-
Front suspension	MacPherson	MacPherson
Rear suspension	multilink	multilink
Tyre dimensions front	235/45 R18	235/45 R18
Tyre dimensions rear	235/45 R18	235/45 R18
Wheel size front	-	-
Wheel size rear	-	-
Brake dimensions front	-	-
Brake dimensions rear	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-
Turning diameter track/circumference [m]	10.0/-	10.0/-

Overall length [mm]	4650	4650
Overall width without/including mirrors [mm]	1820/-	1820/-
Overall height [mm]	1470	1470
Wheelbase [mm]	2700	2700
Front wheel track [mm]	1565	1565
Rear wheel track [mm]	1575	1575
Forward overhang [mm]	-	-
Rear overhang [mm]	-	-
Clearance [mm]	135	135
Wading depth [mm]	-	-
Approach angle front [°]	-	-
Approach angle rear [°]	-	-
Transition angle [°]	-	-
Climbing rate [°]	-	-
Maximum side tilt [°]	-	-

Headroom front [mm]	-	-
Headroom rear [mm]	-	-
Front elbow/shoulder width [mm]	-	-
Rear elbow/shoulder width [mm]	-	-
Legroom front knees/total [mm]	-	-
Legroom rear knees/total [mm]	-	-

Gallery

Suzuki Kizashi FR Sport 2010 front seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
