Suzuki Vitara

Date of manufacture

3/2015 – 2018 (SUV)

Platform

Manufacturing locations

Esztergom, Hungary

Chongqing, People's Republic of China

Designer

Kosei Iwasaki

Toshinobu Ishida

Kanae Ito

Kazuhisa Takayanagi

Yoshitaka Uchiyama

Car body style

SUV

Date of manufacture

3/2015 – 2018

Internal designation

Engine size

Petrol

1.6 VVT

Vitara S 1.4 Boosterjet

Diesel

1.6 DDiS

Euro NCAP

Technical data

SUV

	1.6 VVT	1.6 VVT	1.6 VVT	1.6 VVT	Vitara S 1.4 Boosterjet	Vitara S 1.4 Boosterjet
Date of sale	-	-	-	-	-	-
Engine type	Petrol	Petrol	Petrol	Petrol	Ignition supercharged	Ignition supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1586	1586	1586	1586	1373	1373
Maximum output / speed [kW/min-1]	88/6000	88/6000	88/6000	88/6000	103/5500	103/5500
Maximum torque [Nm/min-1]	156/4400	156/4400	156/4400	156/4400	220/1500-4000	220/1500-4000
Bore and stroke [mm x mm]	78,0 x 83,0	78,0 x 83,0	78,0 x 83,0	78,0 x 83,0	73,0 x 82,0	73,0 x 82,0
Compression ratio	11,0:1	11,0:1	11,0:1	11,0:1	9,9:1	9,9:1
Oil volume [l]	-	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-	-
Technical specifications	variable timing of intake and exhaust valves VVT start&stop system	variable timing of intake and exhaust valves VVT start&stop system	variable timing of intake and exhaust valves VVT start&stop system	variable timing of intake and exhaust valves VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system

Drive axle	Front	Front	4x4	4x4	Front	4x4
Gearbox	5 gear manual	6 gear automatic	5 gear manual	6 gear automatic	6 gear manual	6 gear manual
Drive specifications	-	automatic gearbox	automatically controlled all-wheel drive AllGrip	automatically controlled all-wheel drive AllGrip automatic gearbox	-	automatically controlled all-wheel drive AllGrip

Top speed [km/h]	180	180	180	180	200	200
Acceleration 0–100 km/h [s]	11.5	12.5	12.0	13.0	9.5	10.2
Acceleration 0–80 km/h [s]	-	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-	-

City [l]	6.3	6.6	6.5	6.7	6.1	6.3
Out of town [l]	4.8	4.9	5.1	5.1	4.7	5.0
Combined [l]	5.3	5.5	5.6	5.7	5.2	5.4
CO2 emissions [g/km]	123	127	130	131	121	127

Emission standard	EU6	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-	-
Energy class	-	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-	-

Standby weight [kg]	1150	1195	1235	1260	1215	1285
Overall weight [kg]	1730	1730	1730	1730	1730	1730
Maximum trailer weight unbraked/braked [kg]	400/1200	400/1200	400/1200	400/1200	400/1200	400/1200
Maximum front/rear axle load [kg]	-	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-	-	-

Boot volume [l]	375	375	375	375	375	375
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1120	-/1120	-/1120	-/1120	-/1120	-/1120
Boot length [mm]	-	-	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-	-	-
Loading edge height [mm]	-	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-	-

Number of doors	5	5	5	5	5	5
Number of seats	5	5	5	5	5	5
Fuel tank volume [l]	47	47	47	47	47	47
AdBlue tank volume [l]	-	-	-	-	-	-
Air resistance [Cd]	-	-	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	215/60 R16 95H	215/55 R17 94V	215/60 R16 95H	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V
Tyre dimensions rear	215/60 R16 95H	215/55 R17 94V	215/60 R16 95H	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V
Wheel size front	6.5J x 16	6.5J x 17	6.5J x 16	6.5J x 17	6.5J x 17	6.5J x 17
Wheel size rear	6.5J x 16	6.5J x 17	6.5J x 16	6.5J x 17	6.5J x 17	6.5J x 17
Brake dimensions front	-	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4175	4175	4175	4175	4175	4175
Overall width without/including mirrors [mm]	1775/-	1775/-	1775/-	1775/-	1775/-	1775/-
Overall height [mm]	1610	1610	1610	1610	1610	1610
Wheelbase [mm]	2500	2500	2500	2500	2500	2500
Front wheel track [mm]	1535	1535	1535	1535	1535	1535
Rear wheel track [mm]	1505	1505	1505	1505	1505	1505
Forward overhang [mm]	875	875	875	875	875	875
Rear overhang [mm]	800	800	800	800	800	800
Clearance [mm]	185	185	185	185	185	185
Wading depth [mm]	-	-	-	-	-	-
Approach angle front [°]	-	-	-	-	-	-
Approach angle rear [°]	-	-	-	-	-	-
Transition angle [°]	-	-	-	-	-	-
Climbing rate [°]	-	-	-	-	-	-
Maximum side tilt [°]	-	-	-	-	-	-

Headroom front [mm]	-	-	-	-	-	-
Headroom rear [mm]	-	-	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-	-

	Vitara S 1.4 Boosterjet	1.6 DDiS	1.6 DDiS	1.6 DDiS
Date of sale	-	-	-	-
Engine type	Ignition supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16
Engine displacement [cm³]	1373	1598	1598	1598
Maximum output / speed [kW/min-1]	103/5500	88/3750	88/3750	88/3750
Maximum torque [Nm/min-1]	220/1500-4000	320/1750	320/1750	320/1750
Bore and stroke [mm x mm]	73,0 x 82,0	79,5 x 80,5	79,5 x 80,5	79,5 x 80,5
Compression ratio	9,9:1	16,5:1	16,5:1	16,5:1
Oil volume [l]	-	-	-	-
Coolant volume [l]	-	-	-	-
Technical specifications	direct injection turbo-supercharged variable valve timing sacích VVT start&stop system	direct injection Common Rail turbocharger with variable blade geometry cartridge catalytic converter start&stop system	direct injection Common Rail turbocharger with variable blade geometry cartridge catalytic converter start&stop system	direct injection Common Rail turbocharger with variable blade geometry cartridge catalytic converter start&stop system

Drive axle	4x4	Front	4x4	4x4
Gearbox	6 gear automatic	6 gear manual	6 gear manual	6 gear automatic
Drive specifications	automatically controlled all-wheel drive AllGrip automatic gearbox	-	automatically controlled all-wheel drive AllGrip	automatically controlled all-wheel drive AllGrip dual-clutch automatic gearbox TCSS

Top speed [km/h]	200	180	180	180
Acceleration 0–100 km/h [s]	10.2	11.5	12.4	12.4
Acceleration 0–80 km/h [s]	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-

City [l]	6.4	4.6	4.7	5.2
Out of town [l]	5.0	3.7	4.0	4.1
Combined [l]	5.5	4.0	4.2	4.5
CO2 emissions [g/km]	128	106	111	118

Emission standard	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-
Energy class	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-
Driving noise [dB]	-	-	-	-

Standby weight [kg]	1310	1305	1370	1400
Overall weight [kg]	1730	1870	1870	1870
Maximum trailer weight unbraked/braked [kg]	400/1200	600/1500	600/1500	400/1200
Maximum front/rear axle load [kg]	-	-	-	-
Maximum vertical load on the tow bar [kg]	-	-	-	-
Maximum load on roof/carrier [kg]	-	-	-	-

Boot volume [l]	375	375	375	375
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-/1120	-/1120	-/1120	-/1120
Boot length [mm]	-	-	-	-
Boot length with rear seats folded [mm]	-	-	-	-
Boot width between wheels/max [mm]	-	-	-	-
Boot height to headliner/ceiling [mm]	-	-	-	-
Loading edge height [mm]	-	-	-	-
Height of the open boot door [mm]	-	-	-	-
Boot opening height [mm]	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-

Number of doors	5	5	5	5
Number of seats	5	5	5	5
Fuel tank volume [l]	47	47	47	47
AdBlue tank volume [l]	-	-	-	-
Air resistance [Cd]	-	-	-	-
Front suspension	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs	MacPherson, coil springs
Rear suspension	torsion bar	torsion bar	torsion bar	torsion bar
Tyre dimensions front	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V
Tyre dimensions rear	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V	215/55 R17 94V
Wheel size front	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17
Wheel size rear	6.5J x 17	6.5J x 17	6.5J x 17	6.5J x 17
Brake dimensions front	-	-	-	-
Brake dimensions rear	-	-	-	-
Steering	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m	Rack & pinion with electric power steering m
Number of steering wheel turns	-	-	-	-
Turning diameter track/circumference [m]	10.4/-	10.4/-	10.4/-	10.4/-

Overall length [mm]	4175	4175	4175	4175
Overall width without/including mirrors [mm]	1775/-	1775/-	1775/-	1775/-
Overall height [mm]	1610	1610	1610	1610
Wheelbase [mm]	2500	2500	2500	2500
Front wheel track [mm]	1535	1535	1535	1535
Rear wheel track [mm]	1505	1505	1505	1505
Forward overhang [mm]	875	875	875	875
Rear overhang [mm]	800	800	800	800
Clearance [mm]	185	185	185	185
Wading depth [mm]	-	-	-	-
Approach angle front [°]	-	-	-	-
Approach angle rear [°]	-	-	-	-
Transition angle [°]	-	-	-	-
Climbing rate [°]	-	-	-	-
Maximum side tilt [°]	-	-	-	-

Headroom front [mm]	-	-	-	-
Headroom rear [mm]	-	-	-	-
Front elbow/shoulder width [mm]	-	-	-	-
Rear elbow/shoulder width [mm]	-	-	-	-
Legroom front knees/total [mm]	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-

Gallery

Suzuki Vitara LY 2017 rear folding seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
