Toyota Hilux

Date of manufacture

2015 – 2020 (SUV)

Platform

Toyota IMV

Manufacturing locations

Chachoengsao, Thailand

Designer

Hiroki Nakajima

Car body style

SUV

Date of manufacture

2015 – 2020

Internal designation

AN120/AN130

Engine size

2.4 D-4D Single Cab

2.4 D-4D Extra Cab

2.4 D-4D Double Cab

Euro NCAP

Technical data

SUV

	2.4 D-4D Single Cab	2.4 D-4D Single Cab	2.4 D-4D Extra Cab	2.4 D-4D Double Cab	2.4 D-4D Double Cab
Date of sale	-	-	-	-	-
Engine type	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged	Diesel supercharged
Number of cylinders/valves	4/16	4/16	4/16	4/16	4/16
Engine displacement [cm³]	2393	2393	2393	2393	2393
Maximum output / speed [kW/min-1]	110/3400	110/3400	110/3400	110/3400	110/3400
Maximum torque [Nm/min-1]	400/1600-2000	400/1600-2000	400/1600-2000	400/1600-2000	400/1600-2000
Bore and stroke [mm x mm]	92,0 x 90,0	92,0 x 90,0	92,0 x 90,0	92,0 x 90,0	92,0 x 90,0
Compression ratio	15,6:1	15,6:1	15,6:1	15,6:1	15,6:1
Oil volume [l]	-	-	-	-	-
Coolant volume [l]	-	-	-	-	-
Technical specifications	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection	direct injection Common Rail turbocharger with variable blade geometry particulate filter SCR catalytic converter with AdBlue additive injection

Drive axle	Rear	4x4	4x4	4x4	4x4
Gearbox	6 gear manual	6 gear manual	6 gear manual	6 gear manual	6 gear automatic
Drive specifications	-	connectable all-wheel drive	connectable all-wheel drive	connectable all-wheel drive	connectable all-wheel drive automatic gearbox Super ECT

Top speed [km/h]	175	170	170	170	170
Acceleration 0–100 km/h [s]	13.2	13.2	13.2	13.2	12.8
Acceleration 0–80 km/h [s]	-	-	-	-	-
Acceleration 80–120 km/h [s]	-	-	-	-	-

City [l]	7.9	8.3	8.2	8.2	9.5
Out of town [l]	6.1	6.4	6.3	6.3	6.7
Combined [l]	6.8	7.1	7.0	7.0	7.8
CO2 emissions [g/km]	178	187	185	185	204

Emission standard	EU6	EU6	EU6	EU6	EU6
Standard for fuel consumption measurement	-	-	-	-	-
Energy class	-	-	-	-	-
Stationary vehicle noise [dB]	-	-	-	-	-
Driving noise [dB]	-	-	-	-	-

Standby weight [kg]	1870-1905	1975-2030	2050-2110	2100-2170	2095-2155
Overall weight [kg]	2950	3080	3150	3210	3210
Maximum trailer weight unbraked/braked [kg]	750/2800	750/3500	750/3200	750/3200	750/3200
Maximum front/rear axle load [kg]	-	-	-	-	-
Maximum vertical load on the tow bar [kg]	115	115	130	130	130
Maximum load on roof/carrier [kg]	50/-	50/-	50/-	50/-	50/-

Boot volume [l]	-	-	-	-	-
Boot volume with rear seats folded to the edge of the seats/ceiling [l]	-	-	-	-	-
Boot length [mm]	2315	2315	1840	1525	1525
Boot length with rear seats folded [mm]	-	-	-	-	-
Boot width between wheels/max [mm]	-/1575	-/1575	-/1540	-/1540	-/1540
Boot height to headliner/ceiling [mm]	480/-	480/-	480/-	480/-	480/-
Loading edge height [mm]	-	-	-	-	-
Height of the open boot door [mm]	-	-	-	-	-
Boot opening height [mm]	-	-	-	-	-
Boot opening width min/max [mm]	-	-	-	-	-

Number of doors	2	2	4	4	4
Number of seats	2	2	4	5	5
Fuel tank volume [l]	80	80	80	80	80
AdBlue tank volume [l]	-	-	-	-	-
Air resistance [Cd]	0.394	0.394	0.394	0.394	0.394
Front suspension	double wishbone	double wishbone	double wishbone	double wishbone	double wishbone
Rear suspension	rigid with leaf springs	rigid with leaf springs	rigid with leaf springs	rigid with leaf springs	rigid with leaf springs
Tyre dimensions front	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17
Tyre dimensions rear	225/65 R17	225/65 R17	225/65 R17	225/65 R17	225/65 R17
Wheel size front	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17
Wheel size rear	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17	7.5J x 17
Brake dimensions front	-	-	-	-	-
Brake dimensions rear	-	-	-	-	-
Steering	-	-	-	-	-
Number of steering wheel turns	-	-	-	-	-
Turning diameter track/circumference [m]	12.6/13.4	12.6/13.4	12.8/13.4	12.8/13.4	12.8/13.4

Overall length [mm]	5330	5330	5330	5330	5330
Overall width without/including mirrors [mm]	1800/-	1800/-	1855/-	1855/-	1855/-
Overall height [mm]	1795	1795	1810	1815	1815
Wheelbase [mm]	3085	3085	3085	3085	3085
Front wheel track [mm]	1500	1500	1540	1540	1540
Rear wheel track [mm]	1510	1510	1550	1550	1550
Forward overhang [mm]	1000	1000	1000	1000	1000
Rear overhang [mm]	1250	1250	1250	1250	1250
Clearance [mm]	277	277	289	293	293
Wading depth [mm]	700	700	700	700	700
Approach angle front [°]	30	30	31	31	31
Approach angle rear [°]	25	25	26	26	26
Transition angle [°]	23	23	23	23	23
Climbing rate [°]	42.1	42.1	42.1	42.1	42.1
Maximum side tilt [°]	44.5	44.5	44.5	44.5	44.5

Headroom front [mm]	997	997	997	997	997
Headroom rear [mm]	-	-	969	969	969
Front elbow/shoulder width [mm]	1480/-	1480/-	1480/-	1480/-	1480/-
Rear elbow/shoulder width [mm]	-	-	-	1410/-	1410/-
Legroom front knees/total [mm]	-	-	-	-	-
Legroom rear knees/total [mm]	-	-	-	-	-

Gallery

Toyota Hilux AN120 AN130 Double-Cab 2016 interior

Toyota Hilux AN120 AN130 Double Cab 2017 front seats

Toyota Hilux AN120 AN130 Double Cab 2018 rear seats

Toyota Hilux AN120 AN130 Double Cab 2019 rear seats

Vehicle information and technical data are for guidance only and may contain inaccuracies. Technical data may vary depending on the country of purchase, measurement methodology, selected equipment or installed accessories.

Please always refer to the vehicle registration document or your authorised dealer for exact details.
