Toyota Proace City Verso
Date of manufacture
2019 – to this day (Medium MPV)
Platform
PSA EMP2
Manufacturing locations
Vigo, Spain
Designer
-
Tags
Mid-size MPV
Japanese cars
The Toyota Proace City Verso is a mid-size MPV produced since 2019 in Spain. The vehicle is built on the PSA EMP2 platform and offers petrol and diesel engines with a maximum power of 96 kW in the 1.5 D-4D 130 L2 model. The top speed of this model is 200 km/h, while the 1.5 D-4D 130 L1 with 113 g/km CO2 emissions has the lowest combined fuel consumption of 4.3 l/100 km. The luggage compartment has a volume of 597 l and the car received a rating of 4 out of 5 from EURONCAP in 2018 for safety.
Car body style
Medium MPV
Date of manufacture
2019 – to this dayInternal designation
-
Technical data
Medium MPV
| 1.2 T 110 L1 | 1.2 T 130 L1 | 1.2 T 110 L2 | 1.2 T 130 L2 | 1.5 D-4D 100 L1 | 1.5 D-4D 130 L1 | |
|---|---|---|---|---|---|---|
| Date of sale | - | - | - | - | - | - |
| Engine type | Ignition supercharged | Ignition supercharged | Ignition supercharged | Ignition supercharged | Diesel supercharged | Diesel supercharged |
| Number of cylinders/valves | 3/12 | 3/12 | 3/12 | 3/12 | 4/16 | 4/16 |
| Engine displacement [cm³] | 1199 | 1199 | 1199 | 1199 | 1499 | 1499 |
| Maximum output / speed [kW/min-1] | 81/5500 | 96/5500 | 81/5500 | 96/5500 | 75/3500 | 96/3750 |
| Maximum torque [Nm/min-1] | 205/1750 | 230/1750 | 205/1750 | 230/1750 | 250/1750 | 300/1750 |
| Bore and stroke [mm x mm] | 75,0 x 90,5 | 75,0 x 90,5 | 75,0 x 90,5 | 75,0 x 90,5 | 75.0 x 84,8 | 75.0 x 84,8 |
| Compression ratio | 10.5:1 | 10.5:1 | 10.5:1 | 10.5:1 | 16.4:1 | 16.4:1 |
| Oil volume [l] | - | - | - | - | - | - |
| Coolant volume [l] | - | - | - | - | - | - |
| Technical specifications |
|
|
|
|
|
|
| Drive axle | Front | Front | Front | Front | Front | Front |
| Gearbox | 6 gear manual | 8 gear automatic | 6 gear manual | 8 gear automatic | 5 gear manual | 6 gear manual |
| Drive specifications | - |
| - |
| - | - |
| Top speed [km/h] | 174 | 200 | 174 | 200 | 170 | 186 |
| Acceleration 0–100 km/h [s] | 11.5-11.8 | 12.3 | 11.5-11.8 | 12.3 | 13.3 | 10.3-10.5 |
| Acceleration 0–80 km/h [s] | - | - | - | - | - | - |
| Acceleration 80–120 km/h [s] | - | - | - | - | - | - |
| City [l] | 6.4-6.3 | 6.4-6.3 | 6.4-6.3 | 6.4-6.3 | 4.8-4.6 | 4.8-4.7 |
| Out of town [l] | 4.9-4.8 | 5.1-4.9 | 4.9-4.8 | 5.1-4.9 | 3.9-3.8 | 4.0-3.9 |
| Combined [l] | 5.5-5.3 | 5.6-5.4 | 5.5-5.3 | 5.6-5.4 | 4.2-4.1 | 4.3-4.2 |
| CO2 emissions [g/km] | 125-121 | 127-124 | 125-121 | 127-124 | 111-109 | 113-111 |
| Low speed [l] | - | - | - | - | - | - |
| Medium speed [l] | - | - | - | - | - | - |
| High speed [l] | - | - | - | - | - | - |
| Extra high speed [l] | - | - | - | - | - | - |
| Combined speed [l] | 7.2-6.8 | 7.3-6.9 | 7.2-6.8 | 7.3-6.9 | 5.7-5.3 | 5.8-5.6 |
| CO2 emissions [g/km] | 163-153 | 164-156 | 163-153 | 164-156 | 149-140 | 152-146 |
| Emission standard | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d |
| Standard for fuel consumption measurement | - | - | - | - | - | - |
| Energy class | - | - | - | - | - | - |
| Stationary vehicle noise [dB] | 69 | 69 | 69 | 69 | 68 | 68 |
| Driving noise [dB] | 76/3750 | 75/3750 | 76/3750 | 75/3750 | 74/2813 | 74/2813 |
| Standby weight [kg] | 1366-1667 | 1410-1697 | 1366-1667 | 1410-1697 | 1405-1656 | 1430-1708 |
| Overall weight [kg] | 2050 | 2090 | 2240 | 2090 | 2095 | 2120 |
| Maximum trailer weight unbraked/braked [kg] | 720/950 | 750/1000 | 750/1100 | 750/1200 | 740/1150 | 750/1250 |
| Maximum front/rear axle load [kg] | 1110/1200 | 1200/1260 | 1110-1260 | 1200/1260 | 1110/1200 | 1200/1260 |
| Maximum vertical load on the tow bar [kg] | 50 | 50 | 74 | 74 | 60 | 50 |
| Maximum load on roof/carrier [kg] | 100/- | 100/- | 150/- | 150/- | 100/- | 100/- |
| Boot volume [l] | 597 [65 seven seats] | 597 [65 seven seats] | 850 [209 seven seats] | 850 [209 seven seats] | 597 [65 seven seats] | 597 [65 seven seats] |
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | - | 1672/2693 | 1672/2693 | - | - |
| Boot volume, third row of seats [l] | - | - | - | - | - | - |
| Boot volume, third row seats folded [l] | - | - | - | - | - | - |
| Boot length [mm] | 1000 | 1000 | 1350 | 1350 | 1000 | 1000 |
| Boot length with rear seats folded [mm] | 1880 | 1880 | 2230 | 2230 | 1880 | 1880 |
| Boot width between wheels/max [mm] | 1149/- | 1149/- | 1129/- | 1129/- | 1149/- | 1149/- |
| Boot height to headliner/ceiling [mm] | -/1126 | -/1126 | -/1126 | -/1126 | -/1126 | -/1126 |
| Loading edge height [mm] | 620 | 620 | 620 | 620 | 620 | 620 |
| Height of the open boot door [mm] | - | - | - | - | - | - |
| Boot opening height [mm] | 1119 | 1119 | 1119 | 1119 | 1119 | 1119 |
| Boot opening width min/max [mm] | - | - | - | - | - | - |
| Number of doors | 5 | 5 | 5 | 5 | 5 | 5 |
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 | 5-7 |
| Fuel tank volume [l] | 61 | 61 | 61 | 61 | 50 | 50 |
| AdBlue tank volume [l] | - | - | - | - | 17 | 17 |
| Air resistance [Cd] | - | - | - | - | - | - |
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson | MacPherson |
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms |
| Tyre dimensions front | - | - | 205/60 R16 92H | 205/60 R16 92H | - | - |
| Tyre dimensions rear | - | - | 205/60 R16 92H | 205/60 R16 92H | - | - |
| Wheel size front | - | - | - | - | - | - |
| Wheel size rear | - | - | - | - | - | - |
| Brake dimensions front | - | - | - | - | - | - |
| Brake dimensions rear | - | - | - | - | - | - |
| Steering | - | - | - | - | - | - |
| Number of steering wheel turns | - | - | - | - | - | - |
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- | 10.8/- |
| Overall length [mm] | 4403 | 4403 | 4750 | 4750 | 4403 | 4403 |
| Overall width without/including mirrors [mm] | 1848/2107 | 1848/2107 | 1848/2107 | 1848/2107 | 1848/2107 | 1848/2107 |
| Overall height [mm] | 1837 | 1837 | 1840 | 1840 | 1837 | 1837 |
| Wheelbase [mm] | 2785 | 2785 | 2785 | 2785 | 2785 | 2785 |
| Front wheel track [mm] | 1548 | 1548 | 1548 | 1548 | 1548 | 1548 |
| Rear wheel track [mm] | 1568 | 1568 | 1568 | 1568 | 1568 | 1568 |
| Forward overhang [mm] | 892 | 892 | 892 | 892 | 892 | 892 |
| Rear overhang [mm] | 726 | 726 | 886 | 886 | 726 | 726 |
| Clearance [mm] | - | - | - | - | - | - |
| Wading depth [mm] | - | - | - | - | - | - |
| Approach angle front [°] | - | - | - | - | - | - |
| Approach angle rear [°] | - | - | - | - | - | - |
| Transition angle [°] | - | - | - | - | - | - |
| Climbing rate [°] | - | - | - | - | - | - |
| Maximum side tilt [°] | - | - | - | - | - | - |
| Headroom front [mm] | - | - | - | - | - | - |
| Headroom rear [mm] | - | - | - | - | - | - |
| Front elbow/shoulder width [mm] | 1508/- | 1508/- | 1508/- | 1508/- | 1508/- | 1508/- |
| Rear elbow/shoulder width [mm] | 1509/- | 1509/- | 1509/- | 1509/- | 1509/- | 1509/- |
| Legroom front knees/total [mm] | - | - | - | - | - | - |
| Legroom rear knees/total [mm] | - | - | - | - | - | - |
| Third row of seats, headroom [mm] | - | - | - | - | - | - |
| Third row elbow/shoulder width [mm] | 1200/- | 1200/- | 1198/- | 1198/- | 1200/- | 1200/- |
| 1.5 D-4D 130 L1 | 1.5 D-4D 100 L2 | 1.5 D-4D 130 L2 | 1.5 D-4D 130 L2 | |||
|---|---|---|---|---|---|---|
| Date of sale | from to 2020 | - | - | from to 2020 | ||
| Engine type | Diesel supercharged | Diesel supercharged | Diesel supercharged | Diesel supercharged | ||
| Number of cylinders/valves | 4/16 | 4/16 | 4/16 | 4/16 | ||
| Engine displacement [cm³] | 1499 | 1499 | 1499 | 1499 | ||
| Maximum output / speed [kW/min-1] | 96/3750 | 75/3500 | 96/3750 | 96/3750 | ||
| Maximum torque [Nm/min-1] | 300/1750 | 250/1750 | 300/1750 | 300/1750 | ||
| Bore and stroke [mm x mm] | 75.0 x 84,8 | 75.0 x 84,8 | 75.0 x 84,8 | 75.0 x 84,8 | ||
| Compression ratio | 16.4:1 | 16.4:1 | 16.4:1 | 16.4:1 | ||
| Oil volume [l] | - | - | - | - | ||
| Coolant volume [l] | - | - | - | - | ||
| Technical specifications |
|
|
|
| ||
| Drive axle | Front | Front | Front | Front | ||
| Gearbox | 8 gear automatic | 5 gear manual | 6 gear manual | 8 gear automatic | ||
| Drive specifications |
| - | - |
| ||
| Top speed [km/h] | 181 | 170 | 186 | 181 | ||
| Acceleration 0–100 km/h [s] | 10.6 | 13.3 | 10.3-10.5 | 10.6 | ||
| Acceleration 0–80 km/h [s] | - | - | - | - | ||
| Acceleration 80–120 km/h [s] | - | - | - | - | ||
| City [l] | - | 4.8-4.6 | 4.8-4.7 | - | ||
| Out of town [l] | - | 3.9-3.8 | 4.0-3.9 | - | ||
| Combined [l] | 4.3 | 4.2-4.1 | 4.3-4.2 | 4.3 | ||
| CO2 emissions [g/km] | 113 | 111-109 | 113-111 | 113 | ||
| Low speed [l] | - | - | - | - | ||
| Medium speed [l] | - | - | - | - | ||
| High speed [l] | - | - | - | - | ||
| Extra high speed [l] | - | - | - | - | ||
| Combined speed [l] | - | 5.7-5.3 | 5.8-5.6 | - | ||
| CO2 emissions [g/km] | - | 149-140 | 152-146 | - | ||
| Emission standard | Euro 6d-TEMP | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP - Euro 6d | Euro 6d-TEMP | ||
| Standard for fuel consumption measurement | - | - | - | - | ||
| Energy class | - | - | - | - | ||
| Stationary vehicle noise [dB] | 68 | 68 | 68 | - | ||
| Driving noise [dB] | 74/2813 | 73/2625 | 74/2813 | - | ||
| Standby weight [kg] | - | 1405-1656 | 1430-1708 | - | ||
| Overall weight [kg] | - | 2255 | 2310 | - | ||
| Maximum trailer weight unbraked/braked [kg] | - | 750/1300 | 750/1450 | - | ||
| Maximum front/rear axle load [kg] | - | 1110/1260 | 1200/1260 | - | ||
| Maximum vertical load on the tow bar [kg] | - | 74 | 74 | 74 | ||
| Maximum load on roof/carrier [kg] | - | 150/- | 150/- | 150/- | ||
| Boot volume [l] | 597 [65 seven seats] | 850 [209 seven seats] | 850 [209 seven seats] | 850 [209 seven seats] | ||
| Boot volume with rear seats folded to the edge of the seats/ceiling [l] | - | 1672/2693 | 1672/2693 | 1672/2693 | ||
| Boot volume, third row of seats [l] | - | - | - | - | ||
| Boot volume, third row seats folded [l] | - | - | - | - | ||
| Boot length [mm] | 1000 | 1350 | 1350 | 1350 | ||
| Boot length with rear seats folded [mm] | 1880 | 2230 | 2230 | 2230 | ||
| Boot width between wheels/max [mm] | 1149/- | 1129/- | 1129/- | 1129/- | ||
| Boot height to headliner/ceiling [mm] | -/1126 | -/1126 | -/1126 | -/1126 | ||
| Loading edge height [mm] | 620 | 620 | 620 | 620 | ||
| Height of the open boot door [mm] | - | - | - | - | ||
| Boot opening height [mm] | 1119 | 1119 | 1119 | 1119 | ||
| Boot opening width min/max [mm] | - | - | - | - | ||
| Number of doors | 5 | 5 | 5 | 5 | ||
| Number of seats | 5-7 | 5-7 | 5-7 | 5-7 | ||
| Fuel tank volume [l] | 50 | 50 | 50 | 50 | ||
| AdBlue tank volume [l] | 17 | 17 | 17 | 17 | ||
| Air resistance [Cd] | - | - | - | - | ||
| Front suspension | MacPherson | MacPherson | MacPherson | MacPherson | ||
| Rear suspension | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | twist beam axle with trailing arms | ||
| Tyre dimensions front | - | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Tyre dimensions rear | - | 205/60 R16 92H | 205/60 R16 92H | 205/60 R16 92H | ||
| Wheel size front | - | - | - | - | ||
| Wheel size rear | - | - | - | - | ||
| Brake dimensions front | - | - | - | - | ||
| Brake dimensions rear | - | - | - | - | ||
| Steering | - | - | - | - | ||
| Number of steering wheel turns | - | - | - | - | ||
| Turning diameter track/circumference [m] | 10.8/- | 10.8/- | 10.8/- | 10.8/- | ||
| Overall length [mm] | 4403 | 4750 | 4750 | 4750 | ||
| Overall width without/including mirrors [mm] | 1848/2107 | 1848/2107 | 1848/2107 | 1848/2107 | ||
| Overall height [mm] | 1837 | 1840 | 1840 | 1840 | ||
| Wheelbase [mm] | 2785 | 2785 | 2785 | 2785 | ||
| Front wheel track [mm] | 1548 | 1548 | 1548 | 1548 | ||
| Rear wheel track [mm] | 1568 | 1568 | 1568 | 1568 | ||
| Forward overhang [mm] | 892 | 892 | 892 | 892 | ||
| Rear overhang [mm] | 726 | 886 | 886 | 886 | ||
| Clearance [mm] | - | - | - | - | ||
| Wading depth [mm] | - | - | - | - | ||
| Approach angle front [°] | - | - | - | - | ||
| Approach angle rear [°] | - | - | - | - | ||
| Transition angle [°] | - | - | - | - | ||
| Climbing rate [°] | - | - | - | - | ||
| Maximum side tilt [°] | - | - | - | - | ||
| Headroom front [mm] | - | - | - | - | ||
| Headroom rear [mm] | - | - | - | - | ||
| Front elbow/shoulder width [mm] | 1508/- | 1508/- | 1508/- | 1508/- | ||
| Rear elbow/shoulder width [mm] | 1509/- | 1509/- | 1509/- | 1509/- | ||
| Legroom front knees/total [mm] | - | - | - | - | ||
| Legroom rear knees/total [mm] | - | - | - | - | ||
| Third row of seats, headroom [mm] | - | - | - | - | ||
| Third row elbow/shoulder width [mm] | 1200/- | 1198/- | 1198/- | 1198/- |
